NJU77806F3-TE1 运算放大器

技术规格

电路数 Number of Circuits1	1
电源电压（最低） Supply Voltage (minimum)	1.8V
电源电压（最大） Supply Voltage (maximum)	5.5V
输入失调电压 Input Offset Voltage	2mV
输入失调电流 Input Offset Current	0.001nA
输入偏置电流 Input Bias Current	0.001nA
电源电流 Supply Current	0.6mA
增益带宽积 Gain Bandwidth product	4.4MHz
压摆率 Slew Rate	1.1V/μs
噪音 Noise	5.5nV/√Hz

详细描述

NJU77806 是一款低噪声轨到轨输出 CMOS 运算放大器。它在 1kHz 时提供 5.5nV/√Hz 的低输入电压噪声密度，同时仅消耗 500μA 的电源电流，并具有 4.4MHz 的宽增益带宽和 1.1V/μs 的压摆率。

这些特性使 NJU77806 非常适合需要出色性能的低噪声和低功耗应用。

The NJU77806 is a single low noise rail-to-rail output CMOS operational amplifier. It offers a low input voltage noise density of 5.5nV/√Hz at 1kHz while consuming only 500μA of supply current, and has a wide gain bandwidth of 4.4MHz and slew rate of 1.1V/μs.

These characteristics make the NJU77806 ideal for low noise and low power applications where excellent performance is required.
